UM0306 General purpose and alternate function I/O (GPIO and AFIO)

79/519

Figure 13. High impedance-analog input configuration

FROM ON-CHIP

PERIPHERAL

TO ON-CHIP

PERIPHERAL

Analog Input

I/O PIN

TTL SCHMITT

TRIGGER

VSS

VDD_IO

PROTECTION

DIODE

PROTECTION

DIODE

OFF

INPUT DRIVER

INPUT DATA REGISTER

OUTPUT DATA REGISTER

READ/WRITE

READ

BIT SET/RESET REGISTERS

WRITE
