Power control (PWR) UM0306

44/519

3.5 PWR register map

The following table summarizes the PWR registers.

Refer to Table 1 on page 27 for the register boundary addresses.

Table 9. PWR - register map and reset values

Offset Register

000h

PWR_CR

Reserved

DBP

PLS[2:0]

PVDE

CSBF

CWUF

PDDS

LPDS

Reset Value 000000000

004h

PWR_CSR

Reserved

EWUP

Reserved

PVDO

SBF

WUF

Reset Value 0000
