ST ST32M103 Series User Manual

UM0306 General purpose timer (TIMx)
277/519
13.5.14 Capture/compare register 2 (TIMx_CCR2)
Address offset: 38h
Reset value: 0000h
13.5.15 Capture/compare register 3 (TIMx_CCR3)
Address offset: 3Ch
Reset value: 0000h
1514131211109876543210
CCR2[15:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
Bits 15:0
CCR2[15:0]: Capture/Compare 2 Value.
If channel CC2 is configured as output:
CCR2 is the value to be loaded in the actual capture/compare 2 register (preload
value).
It is loaded permanently if the preload feature is not selected in the TIMx_CCMR2
register (bit OC2PE). Else the preload value is copied in the active capture/compare 2
register when an update event occurs.
The active capture/compare register contains the value to be compared to the counter
TIMx_CNT and signalled on OC2 output.
If channel CC2 is configured as input:
CCR2 is the counter value transferred by the last input capture 2 event (IC2).
1514131211109876543210
CCR3[15:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
Bits 15:0
CCR3[15:0]: Capture/Compare Value.
If channel CC3 is configured as output:
CCR3 is the value to be loaded in the actual capture/compare 3 register (preload
value).
It is loaded permanently if the preload feature is not selected in the TIMx_CCMR3
register (bit OC3PE). Else the preload value is copied in the active capture/compare 3
register when an update event occurs.
The active capture/compare register contains the value to be compared to the counter
TIMx_CNT and signalled on OC3 output.
If channel CC3is configured as input:
CCR3 is the counter value transferred by the last input capture 3 event (IC3).
