Universal synchronous asynchronous receiver transmitter (USART) UM0306

416/519

Bit 3

HDSEL: Half-Duplex Selection.

Selection of Single-wire Half-duplex mode

0: Half duplex mode is not selected

1: Half duplex mode is selected

Bit 2

IRLP: IrDA Low-Power.

This bit is used for selecting between normal and low-power IrDA modes

0: Normal mode

1: Low-power mode

Bit 1

IREN: IrDA mode Enable.

This bit is set and cleared by software.

0: IrDA disabled

1: IrDA enabled

Bit 0

EIE: Error Interrupt Enable.

Error Interrupt Enable Bit is required to enable interrupt generation in case of a

framing error, overrun error or noise error (FE=1 or ORE=1 or NE=1 in the

USART_SR register) in case of Multi Buffer Communication (DMAR=1 in the

USART_CR3 register).

0: Interrupt is inhibited

1: An interrupt is generated whenever DMAR=1 in the USART_CR3 register and

FE=1 or ORE=1 or NE=1 in the USART_SR register.
