UM0306 USB full speed device interface (USB)

447/519

Reception buffer address n ()

Address Offset: [] + n*16 + 8

USB local Address: [] + n*8 + 4

1514131211109876543210

ADDRn_RX[15:1] -

rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw -

Bits 15:1

ADDRn_RX[15:1]: Reception Buffer Address

These bits point to the starting address of the packet buffer, which will contain the

data received by the endpoint associated with the register at the next OUT/SETUP

token addressed to it.

Bit 0

This bit must always be written as ‘0’ since packet memory is word-wide and all packet

buffers must be word-aligned.
