6 TS 500i
2. Specifications
2.1 Engine
STIHL Injection
Control unit with load dependent, characteristic-curve-driven ignition timing adjustment and fuel injection.
Electronic water control
The electronic water control makes it possible to feed the optimum amount of water to the abrasive wheel. No
water is fed to the abrasive wheel during idling.
TS 500i
Displacement: 72.2 cm
3
Cylinder bore: 52 mm
Stroke: 34 mm
Engine power to ISO 7293: 3.9 kW (5.3 HP)
at 9500 rpm
Cut-off speed: 9800 rpm
Max. spindle speed to ISO 19432: 4780 rpm
Idle speed: 2500 rpm
Clutch: Centrifugal clutch without
linings
Clutch engages at: 4000 rpm
Crankcase leakage test
at gauge pressure: p
ü
= 0.5 bar
under vacuum p
u
= 0.5 bar
2.2 Fuel system Fuel system leakage test at
gauge pressure:
p
ü
= 0.8 bar
Operation of tank vent
at gauge pressure: p
ü
= 0.3 bar
Fuel: as specified in instruction
manual
2.3 Spark plug Spark plug (suppressed): Bosch WSR6F
NGK BPMR 7 A
Electrode gap: 0.5 mm
2.4 Abrasive wheels
Composite and diamond cutting wheels Diameter 350 mm
Cutting depth 125 mm
