5 Regular care and maintenance
Lubricants
Lubricants
CAUTION
Risk of damage to property
Trucks for cold store operation must be lubricated
using different lubricants. Refer to the operating
instructions for cold store trucks.
The following lubricants must be used:
Hydraulic system
• Hydraulic oil HLP DIN 51524/T2
• ID no. 8 036 912
The tanks are labelled with a min/max mark-
ing. After the hydraulic oil has been topped up
or changed, the oil level must be between the
min marking and the max marking.
Gearbox
• Gearbox oil SAE 75W-90 API GL-5
• ID no. 732 600 0007
The standard gearbox holds 4.6 litres of
gearbox oil.
The heavy gearbox holds 7 litres of gearbox
oil.
Grease lubrication points
• ESSO Beacon 2 multi-purpose grease
• ID no. 8 010 107
Chain lubrication
• Chain spray Stabylan 2100
• ID no. 8 010 100
Lubricant for the joint between the shaft and
the hub
• Special grease Klüberplex BEM 34-132
• ID no. 8 052 709
94 5
231 804 2502 EN - 11/2017
