Operation 4
General commissioning
Wheel nuts
WARNING
Wheel nuts can loosen after initial commissioning.
After the first eight operating hours, tighten the
wheel nuts to 195 Nm.
Support screws
The setting of the support screws must be
checked during initial commissioning and
each time maintenance is performed.
The setting dimension (1) is dependent on the
application of the truck and can be taken from
the load capacity diagram.
523
1 804 2502 EN - 11/2017 47
