4 Operation
Driving
Driving and auxiliary lift
In order to execute the two functions driving
and auxiliary lift simultaneously, both operat-
ing levers must be moved accordingly.
Press the button (10) to select the auxiliary lift.
The degree of activation is always infinitely
variable.
Driving, main lift and auxiliary lift
In order to execute the functions driving, main
lift lifting and auxiliary lift lifting, or driving,
main lift lowering and auxiliary lift lowering
simultaneously, both operating levers must be
moved accordingly.
In addition, press the button (11) to select the
combination of main lift and auxiliary lift.
The degree of activation is always infinitely
variable.
Moving the load
Main lift and auxiliary lift
The main lift and the auxiliary lift can be lifted
and lowered together. The lift height display
will be synchronised.
Pressing button (1) and moving the left-hand
operating lever in direction (2) or (3) triggers
the infinitely joint lifting or lowering of the main
lift and auxiliary lift.
NOTE
This combined hydraulic function can still be
combined with the driving function. To do this,
move the right-hand operating lever as well.
64 5
231 804 2502 EN - 11/2017
