Operation 4
Driving
Two-hand driving operation
Operation of the industrial truck with two hands
is required within the aisles once the controller
has detected the corresponding sensor
system. To also drive with your left hand,
touch the sensor surface on the left-hand end
of the operating panel (5).
Simultaneous functions
Different functions can be
combined. For this
purpose, more than two oper
ating devices
may need to be actuated at th
esametime.
Driving and main lift
In order to execute the two functions driving
and main lift simultaneously, both operating
levers must be moved accordingly. Moving
the left operating lever in the direction of the
fork (6) activates lowering of the main lift.
Moving this operating lever in the direction of
the lift mast (7) activates lifting. The degree of
activation is always infinitely variable.
The drive directio
n and the driving speed are
selected using the ri
ght-hand operating lever.
Move the operating lever in the direction of the
fork (8) until the required driving speed in the
fork direction has been reached.
Move the operating lever in the direction of the
lift mast (9) until the required driving speed in
the direction of the lift mast has been reached.
523
1 804 2502 EN - 11/2017 63
