3 Overview
Swivel shift fork
Brightness setting
The brightness is automatically adjusted by a
light sensor (1) below the display.
NOTE
For the automatic brightness feature to
function correctly, the sensor must not be
covered or contaminated.
Swivel shift fork
The movements of swivel shift fork are braked
automatically before they reach their me-
chanical and stop. The end positions are
indicated by switches to the control system.
Only when the swivel shift fork is located in its
left or right-hand end position does the truck
travel at the maximum speed permitted for the
lift height. If either the swivel or the side shift
movement has not reached its end stop, the
vehicle travels at positioning speed only. The
symbol in the display for creep speed turtle will
be lit. The end positions of the swivel shift fork
are indicated by an acoustic signal.
38 5
231 804 2502 EN - 11/2017
