Still MX-X - Special Equipment

Special equipment 7
Battery on a roller channel
the rubber buffers must rotate with the
knurled-head screws.
– Tension can be increased by screwing one
of the two knurled-head screws in further.
Tighten the knurled-head screws hand tight.
The battery lock is clamped securely if the
rubber buffer is clearly deformed.
– If sufficient clamping is not
achieved via
these steps, it is possible t
hat a battery with
incorrect dimensions has be
en inserted.
The truck must not be used if t
he battery is
not securely locked. Doing s
o would result
in the risk of accidents and d
amage.
– When the clamping has been carried out, a
thread must still be visible at (5) and (6).
523
