Overview 3
Operating panel
(3) Enable button (for example, as a brake
release button in an automatic braking system
or as bridging for the intermediate lift cut
out and to acknowledge errors that can be
acknowledged)*. Flashes red when it needs
to be pressed.
(4) Manual-automatic two-way switch for
inductive guidance*
(5) Selection keys for favou
rites
(6), (7), (8) Selection keys for hydraulic
additional functions*
(9) Emergency off switch
(10) Operating lever for d
riving
(11) Sensor surface for two-hand operation of
the main lift or shifting in the aisle
(12) Selection key for lifting or lowering the
auxiliary lift or swivelling the fork
(13) Reserved for specia
l functions
(14) Selection key for automatic functions, e.g.
fork cycle
(15) Selection key for lifting or lowering the
cab lift and auxiliary lift together, in connection
with pulling or pushing operating lever (1),
or the selection key for swivelling the fork
synchronously 180° to the left or right in
connection with moving operating lever (1)
to the right or left.
(16) Selection of a menu display
(17) Selection within a menu
(18) Go back one step in the menu or confirm
a selection
(19) Back to the main menu
(20) Light sensor for auto
matic control of the
display lighting
(21) Steering knob or steering wheel
(22) Sensor surface for two-hand driving in the
aisle
* Optional functions
523
1 804 2502 EN - 11/2017 29
