www.stryker.com 2030-809-002 REV D 195
Footboard Assembly, Standard Components, iBed Awareness Option - 3004-500-010
Item Part No. Part Name Qty.
A 0023-103-000 Pan Head Hi - Low Tapping Screw 4
B 0023-118-000 Pan Head Screw 2
C 0050-039-000 Pan Head Screw 2
D 0050-039-000 Pan Head Screw 2
E 3000-050-400 Footboard Laminate 1
F 3000-500-029 Hazard Label 1
G 3001-500-001 Lid Assembly 1
H 3001-500-010 Footboard Assembly 1
J 3001-500-064 Hinge Plate 1
K 3002-500-025 Lid Label 1
L 3004-500-008 LBS Footboard Indicator Light, Ass’y. 1
M 3004-553-011 LBS Footboard PCB Assembly 1
N 3003-500-801 Footboard CAN Cable 1
P 3003-500-804 Lens Footboard Cable 1
R 3003-508-007 Scale Label 1
T 3003-508-008 Bed Status Label 1
Footboard Assembly, iBed Awareness Option
To Next Page
