36. The display should present the following message when the bed is ready to continue:
“Release Button”. The message should be flashing.
37. Release the button and do not touch the bed. When the button is released the following message will be
displayed: “Do Not Touch Bed”. The message should be flashing.
38. The display should present the following message when the bed is ready to continue:
“Press Trend”.
39. Press the trend button.
40. The display should present the following message when the bed in the proper position:
“Release Button”. The message should be flashing.
41. Release the button and do not touch the bed. When the button is released the following message will be
displayed: “Do Not Touch Bed”. The message should be flashing.
42. The display should present the following message when the bed is ready to continue:
“Press Trend”.
43. Press the trend button.
44. The display should present the following message when the bed is ready to continue:
“Release Button”. The message should be flashing.
45. Release the button and do not touch the bed. When the button is released the following message will be
displayed: “Do Not Touch Bed”. The message should be flashing.
46. The display should present the following message when the bed is ready to continue:
“Save Calibration?” “Check – Save” “X – Cancel”.
47. Press the “Enter/Check” button to save the calibration.
48. The display should present the following message when the bed is ready to continue:
“Save Successful”.
Note:
• If an error occurs during the procedure the display will show an error message “Calibration Error” for 4
seconds.
• This procedure should be used after any load cell is replaced
TV Configuration
• This feature allows the operator to set up the TV configuration.
• This configuration provides the product with the information to communicate with the proper entertainment
system.
To Configure the System:
1. In the Maintenance Menu select the TV Configuration item then press and hold the Enter/Check button.
2. The TV Configuration Screen will be displayed. The current TV selection will be highlighted.
3. Use the up and down arrow buttons to highlight the desired item.
4. Press the “Enter/Check” button to select the new setting.
5. The following message will be shown on the display screen when the new setting is saved:
“Save Successful”.
6. The TV Configuration screen should reappear after 2 seconds and the new setting should be highlighted.
7. Pressing the Exit/X button or if the screen remains dormant for more than 30 seconds, the display will return
you to the maintenance menu, without saving any changes.
Service Information
OPTIONAL iBED AWARENESS MAINTENANCE MENU GUIDE (CONTINUED)
Calibrate Scale (Continued)
