Stryker EPIC II Service Manual

Return To Table of Contents
68 2030-809-002 REV D www.stryker.com
EPIC II
®
PLUS OPTION DISPLAY/CPU BOARD REPLACEMENT
Tools Required:
• T27 Torx
• 1/2” Combination Wrench
• #2 Phillips Screwdriver
• Wire Cutters
• Small Regular Screwdriver
• Needle Nose Pliers
• 5/16” Nut Driver
Procedure:
1. Follow steps 1 - 8 of the AC Crossover Board replacement procedure on EPIC II
®
PLUS Option AC Crossover Board
Replacement section.
2. Disconnect all wires from the display/CPU board.
3. Using a #2 Phillips screwdriver, remove the six screws holding the display/CPU board to the control bar cover and
remove the board.
4. Reverse steps 2 & 3 to install the new board.
5. Reverse steps 1 - 8 of the AC Crossover Board replacement procedure on page EPIC II
®
PLUS Option AC
Crossover Board Replacement section to reassemble the bed.
