C7000 INSTRUCTIONS fOR A/C UNITS
Sensors
Range Sensor 1 Sensor 2 Sensor 3 Sensor 4
Purpose 1 - 51 1 2 3 4
Analog input 1 - 4, 6 - 21 100% 200% 300% 4
Type 1 - 5 100% 100% 100% 1
Component configured 0 - 1 100% 100% 0% 0
Min. measure value -150 0°C (-50 - 100) 0%r.h (0 - 100) 0°C (-50 - 100) 0%r.h (0 - 100)
Max. measure value -150 50°C (-50 - 100) 100%r.h (0 - 100) 50°C (-50 - 100) 100%r.h (0 - 100)
Min. output value 0 - 20 4 mA (0 - 20) 4 mA (0 - 20) 4 mA (0 - 20) 4 mA (0 - 20)
Max. output value 0 - 20 20 mA (0 - 20) 20 mA (0 - 20) 20 mA (0 - 20) 20 mA (0 - 20)
Max. difference 0 - 100 10% 10% 10% 10%
Limit - alarm priority 0 - 31 0 0 0 0
Limit - common alarm 0 - 1 1 1 1 1
Limit - alarm delay 0 - 100 5 s 5 s 5 s 5 s
Failure - alarm priority 0 - 31 0% 0% 0% 0
Failure -common alarm 0 - 1 1 1 1 1
Failure - alarm delay 0 - 100 5 s 5 s 5 s 5 s
Offset -50.0 - 50.0 0°C 0% r.h. 0°C 0% r.h.
Range Sensor 5 Sensor 6 Sensor 7 Sensor 8
Purpose 1 - 51 5 6 9 14
Analog input 1 - 4, 6 - 21 500% 600% 700% 8
Type 1 - 5 100% 200% 100% 1
Component configured 0 - 1 0% 0% 0% 0
Min. measure value -150 -50°C (-50 - 100) -20°C (-50 - 100) 0 bar (0 - 35) 0 bar (0 - 35)
Max. measure value -150 50°C (-50 - 100) 40°C (-50 - 100) 30 bar (0 - 35) 30 bar (0 - 35)
Min. output value 0 - 20 4 mA (0 - 20) 0 V (0 - 20) 4 mA (0 - 20) 4 mA (0 - 20)
Max. output value 0 - 20 20 mA (0 - 20) 10 V (0 - 20) 20 mA (0 - 20) 20 mA (0 - 20)
Max. difference 0 - 100 10% 10% 10% 10%
Limit - alarm priority 0 - 31 0 0 0 0
Limit - common alarm 0 - 1 1 1 1 1
Limit - alarm delay 0 - 100 5 s 5 s 5 s 5 s
Failure - alarm priority 0 - 31 0% 0% 0% 0
Failure -common alarm 0 - 1 1 1 1 1
Failure - alarm delay 0 - 100 5 s 5 s 5 s 5 s
Offset -50.0 - 50.0 0°C 0°C 0 bar 0 bar
