C7000 INSTRUCTIONS fOR a/C UNITS
Louver
Sensors (continued)
Value output
Range Louver 1 Louver 2 Louver 3
Pre-start 0 - 180 90 s 90 s 90 s
Output D 0 - 31 700% 0% 0%
Component configured 0 - 1 0% 0% 0%
Range Sensor 9 Sensor 10 Sensor 11 Sensor 12 - 21
Purpose 1 - 51 17 18 21 0
Analog input 1 - 4, 6 - 21 8 10 1 0
Type 1 - 5 2 2 1 0
Component configured 0 - 1 0 0 0 0
Min. measure value -50 - 100 10°C 0 %h.r. 0 bar 0
Max. measure value -50 - 100 30°C 100 %h.r. 10 bar 0
Min. output value 0 - 20 0 V 0 V 4 mA 0
Max. output value 0 - 20 10 V 10 V 20 mA 0
Max. difference 0 - 100% 0% 0% 10 % 0 %
Limit - alarm priority 0 - 31 0 0 0 0
Limit - common alarm 0 - 1 0 0 1 1
Limit - alarm delay 0 - 100 s 0 s 0 s 5 s 5 s
Failure - alarm priority 0 - 31 0 0 0 0
Failure -common alarm 0 - 1 0 0 1 1
Failure - alarm delay 0 - 100 0 s 0 s 5 s 5 s
Offset -50.0 - 50.0 0°C 0 %h.r. 0 bar 0
Range Value output 1 ... Value output 4
Component configured 0 - 1 0 ... 0
Purpose 1 - 51 1 ... 1
Min. limit value -50 - 100 0°C ... 0°C
Max. limit value -50 - 100 50°C ... 50°C
Output A 0 - 20 0 ... 0
