60 EN/06.2019/G57 © STULZ GmbH – all rights reserved
C7000 INSTRUCTIONS fOR a/C UNITS
External Setpoint:
Using the sensor purposes 17 and 18 an external setpoint can be provided.
The external setpoint takes priority over the internal setpoint.
NOTICE
For dry cooler control you have to configure an outside temperature sensor
and a water temperature sensor.
You need two water temperature sensors for:
1. GCW-units with dry coolers
Water temperature 1 is always the temperature for the CW-circuit.
Water temperature 2 is the cooling water temperature, by which the dry coo-
lers are controlled.
2. CW2-units
Water temperature 1 is always the temperature for the CW-valve which is acti-
ve, when no change-over has taken place (no voltage at DIN 3).
Water temperature 2 is the temperature for the second CW-valve, which is
active after a change-over.
25 - Differential pressure 2
26 - Differential pressure 3
27 - Room temperature 1
28 - Supply temperature 1
29 - Room temperature 2
30 - Supply temperature 2
31 - Room temperature 3
32 - Supply temperature 3
33 - Room air pressure
35 - Diff.press. airflow
36 - Outside moisture content
37 - Air volume flow
47 - Supply air pressure in cPa
48 - actual electric power
50 - Water volume flow
51 - electric active power
53 - Water volume flow 2
54 - Water volume flow 3
55 - Ext. setpoint spec humidity
PURPOSE (continued):
