C7000 INSTRUCTIONS fOR a/C UNITS
GE/CW valve
opening
Chillersaver signal
characteristics of GE/CW valve opening
Gradient for GECW valve
(Example: 1,0 K)
Actual temperature
WT setpoint
at the chiller
Note, that the actual temperature,
at which the valve is opened 100%,
depends on the adjusted gradient
because this point is set by the GE/CW
valve opening degree.
SP
For unit version CW2:
In additional operation the chillersaver signal is not available (0% = 0V = highest chiller
WT setpoint).
In changeover operation the chillersaver signal is not available, when a changeover takes
place (0% = 0V).
Chillersaver Function
