16. Coupling with Other Machines
16-2 Allowable Bending Moment, Axial Load
Table 16-2 Allowable Bending Moment (N
･
m)
Frame Size
Model
C14VM, C15VM C17VM, C18VM C24VM, C25VM C27VM, C28VM
608
□
− − 343 687
609
□
343 687 638 1230
610
□
343 687 638 1230
611
□
− − 638 1230
612
□
638 1230 1080 2160
613
□
1080 2160 1570 3140
614
□
1080 2160 1570 3140
616
□
1570 3140 2260 4410
617
□
2260 4410 2940 5890
618
□
2940 5890 3830 7550
619
□
3830 7550 − −
6205 − 10800 − −
6215 − 13700 − −
6225 − 15700 − −
6235 − 18600 − −
6245 − 24500 − −
6255 − 31400 − −
6265 − 37300 − −
Table 16-3 Allowable Axial Load (N)
Frame Size
Model
C14VM, C15VM C17VM, C18VM C24VM, C25VM C27VM, C28VM C3VM
608
□
− − 981 981 −
609
□
981 981 1670 1670 −
610
□
981 981 1670 1670 −
611
□
− − 1670 1670 −
612
□
1670 1670 2650 2650 −
613
□
2650 2650 3730 3730 −
614
□
2650 2650 3730 3730 −
616
□
3730 3730 4910 4910 −
617
□
4910 4910 6180 6180 −
618
□
6180 6180 7650 7650 21600
619
□
7650 7650 − − 32400
6205 − 9810 − − −
6215 − 11800 − − 46100
6225 − 13700 − − 51000
6235 − 15700 − − 51000
6245 − 20600 − − −
6255 − 24500 − − −
6265 − 29400 − − −
Note : 1. The symbol
□
in frame size can be “0” or “5”. For double reduction and triple reduction types, DA, TA, etc. will be appended to the
frame size.
2. Allowable bending moment is the value in the mounting ange.
3. Axial load is possible in the vertical direction. (C3VM only faces downward.)
4. Use is possible up to the allowable value, even if bending moment and axial load are both present. (Except C3VM.)
5. Depending on the bending moment, axial load exceeding the allowable value may be allowed. Please consult us. (Except C3VM.)
6. C3VM values are for reduction ratios of 1/2537 and above.
7. Allowable values are the same for double and triple reduction types.
CYCLO Drive with Vertical Special Base Mount
