Sumitomo CYCLO Service Manual

74
10. Construction Drawings
Common
10-1 Gear Unit Construction Drawings (Single Reduction, Double Reduction)
Figure 10-1 Type CHH (Horizontal, Reducer),
Single Reduction (Example: Frame size 6175)
Figure 10-2 Type CVV (Vertical, Reducer),
Single Reduction (Example: Frame size 6225)
Figure 10-3 Type CHHM (Horizontal, Gearmotor),
Single Reduction (Example: Frame size 6225)
Figure 10-5 Type CNH (Horizontal, Reducer),
Single Reduction (Example: Frame size 6105)
Figure 10-4 Type CNHM (Horizontal, Gearmotor),
Single Reduction (Example: Frame size 6095)
