F.3.6 Device Properties Screen
The Device Properties screen (shown below) displays information about a specific
device. To access this screen, press Alt+D on the SAS Topology screen when the
cursor is on the Device Identifier field of a device.
Press Alt+N or Alt+P at any time while on this screen to cycle to the next or previous
device.
********************************************************************************
* LSI Logic MPT Setup Utility v6.02.00.00 (2005.07.08) *
* Device Properties -- SAS1064 *
* *
* *
* Device Identifier SEAGATE ST936701LSUN36G 0456 *
* Scan Order 2 *
* Device Information SAS *
* SAS Address 5000C500:001047C9 *
* Serial Number 39000SZC 3LC *
* *
* Verify *
* *
* *
* *
* *
* *
**
* Esc=Exit F1=Help Alt+M=More Keys *
* Alt+N = Next Device Alt+P = Previous Device Enter = Select Item *
********************************************************************************
Maximum Link
Speed
The maximum hardware link rate possible for this PHY, in Gbits/s.
Target Capabilities The target capabilities for this device. The following acronyms are
used:
• SSP - Serial SCSI Protocol
• SMP - Serial Management Protocol
Initiator Capabilities The initiator capabilities for this device. The following acronyms are
used:
• SSP - Serial SCSI Protocol
• SMP - Serial Management Protocol
TABLE F-5 SAS Topology Screens Field Descriptions (Continued)
Field Description
