7.0 SG-DRL5/DRL5E/DRL5-2L PSTN Line Cards
- 105 -
6/8/1 Scantronics Super Fast 28 ITI Commader 36 CESA 90
2/16/1 Scantronics Super Fast 29 ITI Security Pro 37 OUTEL 91
4/1 Partial Extended Pulse 52 ITI Caretaker Plus 38 ROBOFON 92
4/1 Extended Pulse 53 ITI SX V 39 VONK 95
4/2 Pulse 54 ITI Commander 2000 3A ADCOR 98
4/2 Extended Pulse 55 CFSK 40 Sur-Gard Generic Internal Messages FF
5/1 Pulse 56 Surtec 4A 4/2 Sur-Gard 7F
Modem IIA 58 Contact ID (10-Digit Account) 4B
Modem IIB 59 BFSK 4C
SG-DRL5 Option 10C/20C: DTMF Cadence
Default (00)
This option will allow the outputted DTMF Cadence (on and off time) to be programmed in milliseconds. The DTMF Cadence option will only be used
for outbound dialling when performing a 2-way audio and line test. This will not affect DTMF for communication format detection or for Contact ID
generation (line test mode). DTMF on - off time tolerance is programming value +/- 5 ms.
The first digit of the option will control the DTMF on time - the second digit will control the DTMF off time, in 25mS increments from 100mS. The
Default setting of 00 will have 100/100ms cadence. Valid range is from 0 to F for both ON time and OFF time.
Digit Value Time (ms) Digit Value Time (ms)
0 100 6 150
1 25 7 175
2 50 8 200
3 75 9 225
4 100 A 250
5 125
Example:
To have a DTMF cadence of 150mS (on and off time) program the option with 66. This option will also allow for cadence settings that are not sym-
metrical. If desired, the on and off times may be different - Example: to have DTMF on time of 75mS and an off time of 200mS, program the option as
38.
SG-DRL5 Option 10D/20D: Line Conditions
Default (000)
Line Conditions is a bit enabled option - If programmed as 00, the line card will detect a single ring. If bit 1 is programmed the line card will detect the
double ring. If bit 2 is enabled the line card will perform a Hook Flash as the end of the call before going on-hook to terminate the call. When the Hook
Flash is performed, a 500mS delay shall be applied prior to the line card going on-hook.
Bit # Option Description
All off Single ring with no Hook Flash
Bit 1 Double ring detection enabled
Bit 2 Reserved - Line Reversal for BABT
Bit 3
Hook Flash on call end enabled. The Hook Flash performed on the call end will follow the time set in the Hook Flash option 11.
If 2-way options are enabled to use Hook Flash then the 2-way session will complete and the Hook Flash for hang-up will be performed.
Examples:
Program the option with 00 for single ring and no Hook Flash for hang-up.
Program the option with 01 (bit 1 set) for double ring and no Hook Flash on hang-up.
Program the option with 04 (bit 3 set) bit for single ring and Hook Flash for hang-up.
Program the option with 05 (bit 1 and 3 set) for double ring and Hook Flash for hang-up.
