Sur-Gard System Five - 2.3.2 UL864 Programming Requirements

2.0 Introduction
- 12 -
For ULC Installations the equipment must be installed in accordance with the requirements of ULC-S561 and ULC-S301 Standards and the authority
having jurisdiction. SG-System 5 with SG-DRL5/DRL5E/DRL5-2L PSTN line cards is ULC listed for passive communication channel security levels
P1-P3 when used in conjunction with compatible alarm systems using Industry Open SIA standard communication formats Contact ID or SIA.
This product has been approved by the California State Fire Marshal (CSFM) pursuant to section 13144.1 of the California Health and Safety Code.
See CSFM Listing No. 7300-1273:0157 for allowable values and/or conditions for use concerning material presented in this document. The approval is
subject to reexamination, revision and possible cancellation.
2.3.2 UL864 programming requirements
NOTE: Users, Installers, Authorities having Jurisdiction and other involved parties; this product incorporates field programmable soft-
ware. In order for the product to comply with the requirements in the Standard for Control Units and Accessories for Fire Alarms
Systems, UL 864, certain programming features or options must be limited to specific values or not used at all as indicated below.
SG-CPM5 - UL864 programming requirements
Opt # Program option Permitted in UL864? (Y/N) Possible settings Settings permitted (UL 864)
202 Buzzer N Enabled/Disabled Enabled
411 Heartbeat Timer Y 00-FF Not Allowed 00
601 CPM5 1 Fan Trouble N Enabled/Disabled Enabled
602 CPM5 2 Fan Trouble N Enabled/Disabled Enabled
603 PSU 1 Trouble N Enabled/Disabled Enabled
604 PSU 2 Trouble N Enabled/Disabled Enabled
609 UPS AC 1 Trouble N Enabled/Disabled Enabled
610 UPS AC 2 Trouble N Enabled/Disabled Enabled
611 UPS Battery 1 Trouble N Enabled/Disabled Enabled
612 UPS Battery 2 Trouble N Enabled/Disabled Enabled
615 SG-Serial Automation Sec 1 Trouble N Enabled/Disabled Enabled
617 Serial CPM 1 Printer 1 Trouble N Enabled/Disabled Enabled
618 Serial CPM 2 Printer 1 Trouble N Enabled/Disabled Enabled
619 Serial CPM 1 Printer 2 Trouble N Enabled/Disabled Enabled
620 Serial CPM 2 Printer 2 Trouble N Enabled/Disabled Enabled
621 SG-TCP Automation Pri - Trouble N Enabled/Disabled Enabled
631 SG-TCP Automation Sec - 1 Trouble N Enabled/Disabled Enabled
665 TCP Printer Pri - 1 Trouble N Enabled/Disabled Enabled
675 TCP Printer Sec - 1 Trouble N Enabled/Disabled Enabled
SG-DRL5-IP
Opt # Program option Permitted in UL 864 (Y/N)
Possible
settings
Settings permitted (UL 864)
221 Transmitter Absent Debounce Time N 5-65535 200
222 Transmitter Restoral Debounce Time N 5-65535 200
301 Transmitter Unencrypted Trouble N Enabled/Disabled Enabled
302 Unknown Account Trouble N Enabled/Disabled Enabled
303 Supervised Accounts Exceeded Trouble N Enabled/Disabled Enabled
SG-DRL5-2L/DRL5E/DRL5
Opt # Program option
Permitted in UL 864?
(Y/N)
Possible set-
tings
Settings permitted (UL
864)
104/204 2-Way Activation Time N 00-FF 00
12F/22F
4- and 5-digit Account Codes to Activate 2-Way
Audio
N 00-FF 00
17B/27B 3-Digit Account Codes to Activate 2-Way Audio N 00-FF 00
17C/27C Alarm Codes to Activate 2-Way Audio N 00-FF 00
17D/27D Supervised Accounts Exceeded Trouble N 00-FF 00
