7.0 SG-DRL5/DRL5E/DRL5-2L PSTN Line Cards

- 110 -

7.5 SG-DRL5 dynamic options: 130/230 - 13F/23F

SG-DRL5 Options 130/230 - 13F/23F: 3/1 - 4/1 Digit 0-F

The line card uses a unique Sur-Gard communication format to transmit data through the System to the central station computer. Event codes cor-

responding to alarm codes in 10 to 40 Baud formats and DTMF 4/1 to 4/3 formats are used in this unique format to enable the computer software to

determine alarm types.

The receiver uses the last digit of data received in 3/1 and 4/1 formats to determine the computer event code. The event code is then transmitted to the

central station computer. Refer to the Decoding Library for the complete set of event codes used by the line card. In Sections 30 through 3F, program

ASCII codes according to the Decoding Library.

Do NOT use values other than 20-7F (ASCII).

SG-DRL5 Options 140/240 - 14F/24F: 3/2 - 4/2 Digit 0-F

Defaults:

Option Value Code

40 - 48 41 A

49 52 R

4A 41 A

4B 4F O

4C 43 C

4D 5C \

4E 52 R

4F 54 T

The line card uses the first digit following the account code in 4/2, 3/1 extended or 3/2 formats to determine the computer event code. The event code is

then transmitted to the central station computer. Refer to the Decoding Library for the complete set of event codes used by the channel.

In Sections 40 through 4F, program ASCII codes according to the Decoding Library.

Do NOT use values other than 20-7F (ASCII).

SG-DRL5 Options 150/250 - 15F/25F: 4/3 Digit 0-F

Defaults:

Option Value Code

50 - 58 41 A

59 52 R

5A 41 A

5B 4F O

5C 43 C

5D 5C \

5E 52 R

5F 54 T

The line card uses the fifth digit of data received in 4/3 formats to determine the message and event code. The event code is then transmitted to the central

station computer. Refer to the Decoding Library for the complete set of messages and event codes used by the line card. In Sections 50 through 5F, pro-
