Sur-Gard System Five - SG-S5 SERCAB - Y-Cable

4.0 Hardware Descriptions and Specifications
- 27 -
4.2.4 SG-S5SERCAB - Y-cable
The Y connector is used to branch out the RJ-45 printer/automation port on the SG-CPM5 to two serial connections:
1. Serial port 1 is for the automation.
2. Serial port 2 is for the printer.
1
2
Serial Pin OUTS:
From To
Connector Pin# Connector Pin#
RJ-45 Male
1
Printer
DB-9
7
2 8
3 2
4 3
5 5
6
Automation
DB-9
2
7 3
8 5
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8
RJ-45 MALE
DB-9
MALE (2)
DB-9
MALE (1)
