Sur-Gard System Five - Option Values

7.0 SG-DRL5/DRL5E/DRL5-2L PSTN Line Cards
- 104 -
SG-DRL5 Option 10A/20A: Format ID Output
Default (00)
Option [410]: Format ID Output
Default(00) - Disabled
This option enables the line card to output the format ID and profile used to receive a call. Output is either to a printer or to automation (for V1.31 and
up).
Option Values
00 – Disabled
01 – Output Format ID to printer only
02 – Output Format ID to automation only
03 – Output Format ID to printer and automation
The string is formatted as follows: (PP|FF|CC)
(= Hex 28
) = Hex 29
| = Hex 7C
PP = Profile number
FF = Format ID
CC = Channel number that received the signal (Phone line 01/02/03). The channel number is outputted in decimal.
For printer output, the string is added to the event signal only (not the caller information output):
Example:
27 Nov 2009-18:51:25-01/06-SG -(PP|FF|CC)-RR-LLL-EVENT MESSAGE
For output to automation, the Format ID is added to the end of the automation string when enabled.
Example 1:
503045 187129E20001007(PP|FF|CC)
Example 2:
R03689[#1075|NRP](PP|FF|CC)
Format ID List
Format Description
Format
ID
Format Description
Format
ID
Format Description
Format
ID
3/8 ACRON 1 Modem II Generic 5a 3/1 Pulse 4D
4/8 ACRON 2 Modem IIE or IIIa2 5b 3/2 Pulse 4E
4/1 Express 10 4/3 Sescoa Super Speed 69 4/1 Pulse 4F
4/2 Express 11 Sescoa Open/Close
Super Speed
6A 3/1 Extended Pulse 50
3/8/1 Ademco Super Fast 13 SIA FSK Level 1, 2 and 3 6B 3/1 Partial Extended Pulse 51
4/8/1 Ademco Super Fast 14 Silent Knight FSK0 7A 4/2 Sur-Gard 7F
4/8/1 with Checksum Ademco Super Fast 15 Silent Knight FSK1 7B 4/2 with Checksum Sur-Gard 7F
Contact ID (4-Digit Account) 16 Silent Knight FSK2 o/p Type 1 7C 4/3 Sur-Gard 80
Bellcore Caller-ID 1B Silent Knight FSK2 o/p Type 2 7D 4/3 with Checksum Sur-Gard 80
Bellcore Caller-Name 1D 4/1 Partial Extended Pulse 52 4/1 Varitech 85
DMP Serial 1 21 3/16/1 Scantronics Super Fast 2A 4/2 Varitech 86
DMP Serial 3 22 4/16/1 Scantronics Super Fast 2B Westec 1 8A
4/3/1 FBI Super Fast 24 5/16/1 Scantronics Super Fast 2C Westec 2 8B
4/3/1 with Checksum FBI Super Fast 25 6/16/1 Scantronics Super Fast 2D Westec 3 8C
2/8/1 Scantronics Super Fast 26 ITI Generic 33 Westec 5 8D
5/8/1 Scantronics Super Fast 27 ITI Commader III 34 Westec 6 8E
