Appendix D: Events and Messages
- 136 -
Appendix D: Events and Messages
SG-CPM5 messages
NOTE: The slots (ss) of the SG-CPM5 are C1 for the primary and C2 for secondary.
Description/event Automation message Printer message
SG-PSU5 1 Failure
PSU is Missing, Temperature trouble, power over-
load trouble or unknown hardware ID
001000[#0000|NAT0000] SG -01-000-0000-NAT0000-SG-PSU 1 Failed
SG-PSU5 1 Restoral 001000[#0000|NAR0000] SG -01-000-0000-NAR0000- SG-PSU 1 Restored
SG-PSU5 2 Failure
PSU is Missing, Temperature trouble, power over-
load trouble or unknown hardware ID
001000[#0000|NAT0001] SG -01-000-0000-NAT0001- SG-PSU 2 Failed
SG-PSU5 2 Restoral 001000[#0000|NAR0001] SG -01-000-0000-NAR0001- SG-PSU 2 Restored
PSU Compatibility Failure (the two installed power
supplies are not at the same power rating)
001000[#0000|NYP00FF] SG -01-000-0000-NYP00FF-PSU Compatibility Failed
PSU Compatibility Restore 001000[#0000|NYQ00FF] SG -01-000-0000-NYQ00FF-PSU Compatibility Restore
Fan Circuit 1 Failure (LINE CARD FAN 1) 001000[#0000|NYX0100] SG -01-000-0000-NYX0100-Fan Circuit 1 Failed
Fan Circuit 1 Restoral Fan (LINE CARD FAN 1) 001000[#0000|NYZ0100] SG -01-000-0000-NYZ0100-Fan Circuit 1 Restored
Fan Circuit 1 Warning 50% Fan (LINE CARD FAN
1)
001000[#0000|NYU0100] SG -01-000-0000-NYU0100-Fan Circuit 1 50% Warning
Fan Circuit 2 Failure Fan (LINE CARD FAN 2) 001000[#0000|NYX0200] SG -01-000-0000-NYX0200-Fan Circuit 2 Failed
Fan Circuit 2 Restoral Fan (LINE CARD FAN 2) 001000[#0000|NYZ0200] SG -01-000-0000-NYZ0200-Fan Circuit 2 Restored
Fan Circuit 2 Warning 50% Fan (LINE CARD FAN
2)
001000[#0000|NYU0200] SG -01-000-0000-NYU0200-Fan Circuit 2 50% Warning
Fan Circuit 3 Failure (LINE CARD FAN 3) 001000[#0000|NYX0300] SG -01-000-0000-NYX0300-Fan Circuit 3 Failed
Fan Circuit 3 Restoral Fan (LINE CARD FAN 3) 001000[#0000|NYZ0300] SG -01-000-0000-NYZ0300-Fan Circuit 3 Restored
Fan Circuit 3 Warning 50% Fan (LINE CARD FAN
3)
001000[#0000|NYU0300] SG -01-000-0000-NYU0300-Fan Circuit 3 50% Warning
Fan Circuit 4 Failure Fan (LINE CARD FAN 4) 001000[#0000|NYX0400] SG -01-000-0000-NYX0400-Fan Circuit 4 Failed
Fan Circuit 4 Restoral Fan (LINE CARD FAN 4) 001000[#0000|NYZ0400] SG -01-000-0000-NYZ0400-Fan Circuit 4 Restored
Fan Circuit 4 Warning 50% Fan (LINE CARD FAN
4)
001000[#0000|NYU0400] SG -01-000-0000-NYU0400-Fan Circuit 4 50% Warning
Fan Circuit 5 Failure (CPM FAN 1) 001000[#0000|NYX0500] SG -01-000-0000-NYX0500-Fan Circuit 5 Failed
Fan Circuit 5 Restoral Fan (CPM 1 FAN) 001000[#0000|NYZ0500] SG -01-000-0000-NYZ0500-Fan Circuit 5 Restored
Fan Circuit 5 Warning 50% Fan (CPM 1 FAN) 001000[#0000|NYU0500] SG -01-000-0000-NYU0500-Fan Circuit 5 50% Warning
Fan Circuit 6 Failure Fan (CPM 2 FAN) 001000[#0000|NYX0600] SG -01-000-0000-NYX0600-Fan Circuit 6 Failed
Fan Circuit 6 Restoral Fan (CPM 2 FAN) 001000[#0000|NYZ0600] SG -01-000-0000-NYZ0600-Fan Circuit 6 Restored
Fan Circuit 6 Warning 50% Fan (CPM 2 FAN) 001000[#0000|NYU0600] SG -01-000-0000-NYU0600-Fan Circuit 6 50% Warning
TCP/IP CPM 1 Printer Failure 001000[#0000|NVZ0100] SG -01-000-0000-NVZ0100-TCP/IP 1 Printer Failed
TCP/IP CPM 1 Printer Restoral 001000[#0000|NVY0100] SG -01-000-0000-NVY0100-TCP/IP 1 Printer Restored
TCP/IP CPM 2 Printer Failure 001000[#0000|NVZ0200] SG -01-000-0000-NVZ0200-TCP/IP 2 Printer Failed
TCP/IP CPM 2 Printer Restoral 001000[#0000|NVY0200] SG -01-000-0000-NVY0200-TCP/IP 2 Printer Restored
Serial CPM 1 Printer 1 Failure 001000[#0000|NVZ0102] SG -01-000-0000-NVZ0102-Serial 1 printer Failed
Serial CPM 1 Printer 1 Restoral 001000[#0000|NVY0102] SG -01-000-0000-NVY0102-Serial 1 printer Restored
Serial CPM 2 Printer 1 Failure 001000[#0000|NVZ0202] SG -01-000-0000-NVZ0202-Serial 2 printer Failed
Serial CPM 2 Printer 1 Restoral 001000[#0000|NVY0202] SG -01-000-0000-NVY0202-Serial 2 printer Restored
Serial CPM 1 Printer 2 Failure 001000[#0000|NVZ0103] SG -01-000-0000-NVZ0103-Serial 3 printer Failed
Serial CPM 1 Printer 2 Restoral 001000[#0000|NVY0103] SG -01-000-0000-NVY0103-Serial 3 printer Restored
Serial CPM 2 Printer 2 Failure 001000[#0000|NVZ0203] SG -01-000-0000-NVZ0203-Serial 4 printer Failed
Serial CPM 2 Printer 2 Restoral 001000[#0000|NVY0203] SG -01-000-0000-NVY0203-Serial 4 printer Restored
SG-TCP/IP #1 CPM 1 Failure 001000[#0000|NNT0100] SG -01-000-0000-NNT0100-SG-TCP/IP 1 Failed
