7.0 SG-DRL5/DRL5E/DRL5-2L PSTN Line Cards
- 109 -
When the DMP panel calls in and requests a time update, the receiver will respond with its current time and the offset value programmed in this section.
The time and date of the receiver with respect to the Greenwich Mean Time (GMT). The gg values in the update time and date command are determined
by starting at the GMT and moving westerly across the Earth. The table below will be used to determine the time zone for the option value.
Possible Values Time Zone Description Time Zone
Military Civilian
00 Disabled No time update will be sent to the panels NA
24 Zulu Greenwich Mean Time (GMT) GMT (0)
23 Alpha Central Europe Time (CET)
Middle European Time (MET)
GMT + 1
22 Bravo Eastern Europe Time (EET) GMT + 2
21 Charlie Baghdad Time (BT) GMT + 3
20 Delta Gulf Standard Time (GST) GMT + 4
19 Echo Pakistan Time (PKT) GMT + 5
18 Foxtrot Bangladesh Time (BDT) GMT + 6
17 Golf Java Time (JT) GMT + 7
16 Hotel China Coast Time (CCT) GMT + 8
15 India Japan Standard Time (JST) GMT + 9
14 Kilo Guam Standard Time (GST) GMT + 10
13 Lima Solomon Islands Time (SBT) GMT + 11
12 Mike New Zealand Standard Time (NZST) GMT + 12
01 November Cape Verde Time (CVT) GMT - 1
02 Oscar Greenland Eastern Standard Time (VTZ) GMT - 2
03 Papa Eastern Brazilian Standard Time (BST) GMT - 3
04 Quebec Atlantic Standard Time (AST) GMT - 4
05 Romeo Eastern Standard Time (EST) GMT - 5
06 Sierra Central Standard Time (CST) GMT - 6
070 Tango Mountain Standard Time (MST) GMT - 7
080 Uniform Pacific Standard Time (PST) GMT - 8
09 Victor Alaska Standard Time (AKST) GMT - 9
10 Whiskey Hawaii Standard Time (HST) GMT - 10
11 X-Ray Nome Time (NT) GMT - 11
SG-DRL5 Option 12F/22F: Online Time Out
Default (1E)
The Online Time Out option hangs up after a predetermined time delay. Time Out range can be programmed from 01 to 255 seconds (Hex 01 - FF) or
until the call is completed by the panel (Hex 00). When time out occurs, the line card hangs up and generates a signal to the printer and to the automation
(SIA identifier YS).
For Example:
Printer Message: "DRL Online Time-Out"
Automation: NYS0102 (shelf 01, slot 02).
00 = Disabled.
xx = Maximum number of seconds (Hex) before the receiver will automatically force termination of a call.
NOTE: Depending on the order of handshakes used, the default online timeout of 30 seconds may not allow sufficient time for all hand-
shakes to be sent before timeout occurs. This time may need to be extended to use these handshakes.
For UL Listed products, the permitted setting is 1E (30s).
