17. Electrical System
17-14
Removal of meter
Remove wind screen garnish, wind screen, meter
visor, front cover, meter visor.
(Refer chapter 14)
Disconnect the coupler of the speedometer, and
take off the meter panel and meter.
Loosen 4 screws from meter panel.
Remove the speedometer.
Installation of meter
Install in reverse order of removal procedures
4 screws
Meter coupler
