15. Steering / Front Wheel / Front Cushion
15-5
Front Wheel
Loosen 2 bolts from the front brake caliper and
remove it
Caution
y Care shall be taken not to push the brake
lever to avoid the brake pad being squeezed
out. In case that the brake pad is accidentally
squeezed out, use a screwdriver to force it
back to the place.
Loosen screw & remove speedometer cable.
Turn loose the axle nut.
Pull out the front wheel axle.
Remove the front wheel and both side collar.
Speedometer cable
Axle nut
2 screws
