4. Fuel Injection System
4-14
Precautions in Operation
General information
Warning
● Gasoline is a low fire point and explosive material. Always work in a well-ventilated place and flame is
strictly prohibited when working with gasoline.
● Before dismantling fuel system parts, leak fuel out first, or grip the fuel pipe by using pliers to prevent
fuel from splashing.
Cautions
● Do not bend or twist the throttle cable. Damaged cable will lead to unstable driving.
● When disassembling fuel system parts, pay attention to O-ring position, replace with new one as
re-assembly.
Specification
Item Specifications
Idle RPM 1650±100 rpm
Throttle handle free play 2~6 mm
Fuel pressure 294±6kPa (about 3.0kg/cm²)
Torque value
Engine Temperature sensor 0.74~0.88 kgf-m
O
2 Sensor 3.6~4.6 kgf-m
Special Tools
Vacuum Gauge
Fuel Pressure Gauge
EFi System Diagnostic Scanner
Fuel Pipe Pliers
