5
. Removal & Installation of Engine
5-9
Rear Fork
Bearing Inspection
Check bearings on rear fork.
Rotate bearing inner ring with fingers.
Check if bearing can be turned in smooth and
silent, and also check if bearing outer ring is
mounted on rear fork tightly.
If bearing rotation is uneven, noising, or loose
bearing mounted, then replace it.
Bearing removal
Remove bearing mounting cir clip.
Drive the bearing out of the rear fork.
Bearing installation
Install new rear axle bearing and baring puller into
rear fork.
Special Service Tools:
Rear fork bearing puller SYM-6303000-6303
Install the washer of the 6303 bearing puller.
To this chapter contents
Cir clip
6303 bearing puller
6303 bearing puller washer
