13. Body Cover
13-12
Rear Body Cover
Remove
Loosen right and left side screws from rear end of
floor panel.
Loosen right and left side screws from rear side of
the body cover.
Disconnect the tail light coupler.
Remove the body cover.
Installation
Install in reverse order of removal procedures.
Tail light coupler
Each side 1 screw
Each side 1 screw
