14. Brake System
14-1
Mechanism Diagram···························· 14-1
Precautions in Operation···················· 14-2
Troubleshooting ·································· 14-3
Disk Brake System Inspection············ 14-4
Adding Brake Fluid······························ 14-5
Brake Fluid Replacement / Air-bleed·· 14-6
Front Brake Caliper······························ 14-7
Rear Brake Caliper······························· 14-8
Brake Disk ············································ 14-9
Master Cylinder···································· 14-9
Mechanism Diagram
Front brake Master cylinder
3.0~4.0kgf-m
Delay valve
Front brake caliper
Rear brake Master cylinder
Rear brake caliper
