10. AC. Generator / Start Clutch
10-8
Flywheel Installation
Install starting driven gear onto one way clutch.
Align the key on crankshaft with the flywheel
groove, and then install the flywheel.
Hold the flywheel by drive face with universal
holder, and tighten flywheel nut.
Torque value: 5.0~6.0kgf-m
Special tool:
Universal Holder SYM-2210100
To this chapter contents
Starting driven gear
Groove
