10. AC. Generator / Start Clutch
10-7
Remove the starting gear
Loosen 3 starting clutch socket bolts from one way
clutch and remove one way clutch.
Push out the roller set and check each roller for
wear or damage.
One way clutch Installation
Install the components in the reverse procedures
of removal.
Torque value: 1.0~1.4kgf-m
Caution
y Cannot lock the thread of socket bolt.
Caution
y The one way clutch must to with the generator
flywheel and the starter gear, after one and
loads the crank in, only then may lock the
socket bolt, otherwise will create concentric the
deviation, will cause the part to suffer injury.
To this chapter contents
3 bolts
One way clutch
Starting driven gear
