13. Body Cover
13-11
Luggage Box
Remove
Open the seat.
Loosen 2 screws from the luggage box rear cover.
Disconnect the luggage box light and switch
coupler.
Remove the luggage box rear cover.
Loosen 2 bolts from luggage box front side
Loosen 4bolts from luggage box rear side.
Remove the luggage box.
Installation
Install in reverse order of removal procedures.
2 screws
2 bolts
4 bolts
