13. Body Cover
13-2
Maintenance
Body covers disassemble sequence:
y Be careful not to damage various covers in assembly or disassembly operation.
y Never injure hooks molded on the body covers.
y Align the buckles on the guards with slot on the covers.
y Make sure that each hook is properly installed during the assembly.
y Never compact forcefully or hammer the guard and the covers during assembly.
Rear fender
Under cover
R/L. Handle covers
Floor panel
Handle upper cover
Inner box
Luggage box & seat
Front fender
Wind screen
Meter visor
Front cover
Meter panel
Front under spoiler
Wind screen garnish
Rear carrier
R/L. side cover
R/L body cover
R/L. side cover Rear mudguard
