6. Cylinder Head / Valve
6-4
Cylinder Head Removal
Remove engine. (Refer to chapter 5)
Remove 2 bolts of thermostat and then remove
the thermostat.
Remove hole bolt and spring for the cam chain
tensioner.
Loosen 2 bolts, and then remove tensioner.
Remove thermostat (2 bolts).
Remove Air Injection system (AI) pipe mounting
bolts.
Remove spark plug.
Remove cylinder head cover (4 bolts).
4 bolts
Tensioner bolts
Thermostat bolts
To this chapter contents
4 bolts
