8
. V-Belt Drive System
8-3
Left Crankcase Cover
Left crankcase cover removal
Loosen 4 bolts from left side crank out cover &
remove it.
Remove left crankcase cover. (8 bolts)
Remove 2 dowel pin and gasket.
Left crankcase cover install
Install left crankcase cover in the reverse
procedures of removal.
To this chapter contents
8 bolts
Left cover plate
Bearing setting plate
Drive shaft holder bearing
