Chapter 5 Command Reference
Status Reporting
100 Operating and Programming Manual
Table 5-4. IEEE Standard Event Status Register (ESR)
Bit
Function Name
0
OPC IEEE Operation complete
1
RQC (not used)
2
SCPI Query error
3
SCPI Device Dependent Error
4
SCPI Execution Error
5
SCPI Command Error
6
URQ (not used)
7
PON Power On flag
Table 5-5. SCPI OPERation Status Register
Bit
Function Name
Bit Status
0
CALibrating
Set when performing auto calibration
1
SETTling
always zero
2
RANGing
always zero
3
SWEeping
always zero
4
MEASuring
always zero
5
awaiting TRIG
always zero
6
awaiting ARM
always zero
7
CORRecting
always zero
8
Standby
Set when in standby state
9
On Battery
Set when power source is internal
battery (this will always be 0 for 48V
option instruments).
10
Normal
Set when operating normally
11
Fatal
Set when in fatal error state
12
Steered
Set when output frequency is being
steered
13
INST summary
always zero
14
PROG running
always zero
15
Unused
always zero
