Chapter 1 Getting Started
Starting the 5071A
8 Operating and Programming Manual
Starting the 5071A
1 Inspect the instrument for any damage (see page 119 for details).
2 Ensure that the ac-power setting, ac line fuse, (rear panel) and supplied power
cord are appropriate for the ac-power source.
Refer to Chapter 7, ―Installation,‖ for more detailed information.
3 Apply power to the instrument.
The amber Attention light illuminates, indicating normal power-up sequence, and
the following messages are displayed on the LCD.
The message ―Waiting for Stabilizationmay appear. If so, it could stay on for
up to 20 minutes before the following messages appear.
a. Warming up (Indicates self-test passed successfully.)
b. Setting Osc. Control
c. Setting RF amplitude
d. Setting E_mult voltage
e. Logging signal levels
f. Setting C-field
g. Locking servo loops
h. Operating normally
4 After about 15 minutes, the Attention (amber) light goes out and the Continuous
(green) light flashes.
5 Press Shift (in the ACTIONS keypad section), then 5 (Utilities): LCD display
shows RESET.
Press Enter: This resets the continuous operation circuit, causing the light to be
on steadily. Any subsequent fault will cause the Continuous Operation light to
go out or flash. (See Chapter 3 for details.)
