Chapter 5 Command Reference
Status Reporting
Operating and Programming Manual 99
Status Reporting
The 5071A status registers conform to the SCPI and IEEE 488.2 standards
applicable with an RS-232C serial data-communications port. RS-232C does not
support serial poll, parallel poll, or SRQ. Instead, IEEE SRQ and RQS signals
will always have the same state, and will be reflected in the state of the (low
TRUE) status output port (rear-panel Status Output BNC connector).
The conditions under which the rear-panel Status Output goes active can be
programmed with the commands available in the SCPI STATus subsystem.
These commands are used in conjunction with IEEE 488.2 Common commands.
Refer to the next section of this chapter for information about, and examples of,
programmed rear-panel Status Output states. The status registers of the 5071A
are defined in tables 5-3, 5-4, 5-5, and 5-6 as follows:
Table 5-3. IEEE Summary Status Byte (STB)
Bit
Function
Bit Status
0
unused
1
unused
2
unused
3
QUE
Summary of SCPI QUEStionable status register
4
MAV
IEEE 488.2 MAV bit (unused, always zero)
5
ESB
Summary of IEEE 488.2 Event Status Register
6
MSS
IEEE 488 request status (same state as status port)
7
OPR
Summary of SCPI OPERation status register
