Page #165 background image
Appendix A Performance Tests
Equipment Required
Operating and Programming Manual 137
Equipment Required
Equipment required for the performance tests in this chapter is listed in Table A-
1. Any equipment that satisfies the critical specification listed in the table may be
substituted for the recommended model(s). (The performance test and diagnostic
procedures assume the use of the listed equipment.)
If operational verification (OV) or complete-performance tests (P) are being
performed, use the test equipment that is indicated for operational verification
and/or performance tests in Table A-1.
If diagnostic troubleshooting is required, use the test equipment that is indicated
for troubleshooting use in Table A-1.
Table A-1. Recommended Test Equipment
Instrument
Required Characteristics
Use*
Model
General-Purpose
Oscilloscope
At least 100 MHz bandwidth
Input: 1 M
OV, T
HP/Agilent
54600A
Spectrum Analyzer
Frequency Range Span: 0 to 40 MHz
Measurement Resolution 1 kHz/Div.
Center Frequency Accuracy: 1 PPM
P, T
HP/Agilent
3585A/B
Linear Phase
Comparator
Input Frequency Range: 5 to 10 MHz
Input Level (50 ): 1 Vrms
Output: 0 to +1 Vdc
Output Linearity: Proportional from
0 to 360 degrees phase
P
No recommenda-
tion. Use a phase
comparator or
equivalent
software.
Strip Chart Recorder
Paper Movement: 1 inch/hour
Input Range: 0 to +1 Vdc
Full Scale Range: +1 Vdc
Full Scale Resolution: 50 minor
divisions
P
No
Recommendation
Digital Multimeter
Input Resistance: 10 M
Accuracy: 0.04% at 1 Vdc
T
HP/Agilent
34401A
40kV ac/dc High
Voltage Probe
Range:5KV dc, input Z = 1 G ,
Accuracy: 2%, 10 M load
T
HP/Agilent
34300A
Clip-on Current
Probe
Range: ≤ 1 Amp dc
Output: 1 Vdc at 10 Amp dc
T
HP/Agilent
34302A
Universal Counter
Range: ≤ 500 MHz
Accuracy: 0.1 PPM
T
HP/Agilent
53131A,
Opt 010, 030
