Appendix A Performance Tests
Equipment Required
138 Operating and Programming Manual
Table A-1. Recommended Test Equipment (Continued)
Instrument
Required Characteristics
Use*
Model
CW Microwave
Counter
Range: ≤ 10 GHz
Accuracy: ≤ 0.1 PPM
T
HP/Agilent
5350B,
Option 010
Spectrum Analyzer
Frequency Range: ≤ 9.5 GHz
Resolution: 100 kHz / Division
Center Frequency Accuracy: 1 PPM
Input: Up to 1 Watt input capability
Dynamic Range: 100 dB
T
HP/Agilent
8566A/B
Input Probe
10:1 Divider (included with
54600A oscilloscope)
T
HP/Agilent
10071A
Input Probe
1:1 1 M (for 50 measurements)
T
HP/Agilent
10070A
RF Signal Generator
Frequency Range: > 80 MHz
Power: ≤ +7 dBm
T
HP/Agilent
8656B
Pulse Generator
Repetition Rate: 10 Hz
Pulse Width: ≤ 10 µsec
Output Voltage: ≤ +3V
T
HP/Agilent
8111A
General-purpose DC
Power Supply,
Adjustable 0 - 10V, ≤ 25 ma
T
HP/Agilent
E3610A
IBM-Compatible PC
MS-DOS® 3.3 or later, 640 kB RAM, 1
serial (COM: ) Port
T
Any Vendor
Service Accessories
Kit
Special Test Tools, Devices, and
Fixtures
T
05071-67003
Profiling Software
For Online CBT Performance
Testing(included as P/O Service
manual)
T
05071-13501
BNC cables
BNC Cables, 50 , 1 meter long,
quantity 4
T
HP/Agilent
10503A
Serial Interface cable
RS-232 Cable, 9-pin (jack) to 9-pin (jack)
T
HP/Agilent
24542U
