Symmetricom 5071A User Manual

Appendix A Performance Tests
Equipment Required
Operating and Programming Manual 139
Table A-1. Recommended Test Equipment (Continued)
Instrument
Required Characteristics
Use*
Model
Adapters
50 BNC In-line Feedthrough
2-Way 3dB Power Splitter
BNC (jack) to BNC (jack), quantity 4
BNC (jack) to SMC (plug), quantity 2
BNC (plug) to SMC (jack)
BNC (jack) to SMB (plug)
BNC (plug) to SMB (jack)
N (plug) to BNC (jack)
N (plug) to SMA (jack)
SMA (jack) to SMA (plug) Right-Angle
SMA (plug) to SMA (plug)
SMA (jack) to SMA (jack)
SMB (jack) to SMB (jack)
SMB (plug) to SMB (plug)
SMC (jack) to SMC (jack)
SMC (plug) to SMC (plug)
T
HP/Agilent
10100C
0960-0496
1250-0080
1250-0832
1250-0831
1250-1236
1250-1857
1250-0780
1250-1250
1250-1249
1250-1159
1250-1158
1250-0672
1250-0669
1250-0827
1250-1113
Microwave Test
Cable
SMA (male) at both ends, < 10 dB loss
at 10 GHz
T
GoreTex
32R01R01048.0
Special Tools
Narrow bladed non-conducting
screwdriver
TORX® T-8 Driver
TORX® T-10 Driver
TORX® T-15 Driver
TORX® T-25 Driver
T
Jacobsen #8777
8710-1614
8710-1623
8710-1622
8710-1617
*OV = Operational Verification
P = Complete Performance Tests
T = Troubleshooting
