Tadiran Telecom FlexSet 280D - Wall Mounting Installation

Product Features and Model Designations l FlexSet 120/280 User Guide
Lift up the tab
from the opening
Rotate the tab
Re-insert the tab
into the opening
Step 1
Step 2
Step 3
Handset Hook Rotation
Step 5
Snap the legs located
on the thick edge of the
bracket into the lower
wide slots on the back
of the phone.
Step 4
Place the bracket’s legs,
located on the thin edge
of the bracket, into the
narrow slots on the back
of the phone.
Bracket Installation
Wall Mounting Installation
