3. Installation
50 Instructions for Use for infinite® 200 No. 30017581 Rev. No. 1.4 2008-07
4. Loosen the screw from other transport lock, which is only in the plate
carrier compartment (right transport lock in picture above).
5. Pull the plate carrier out manually.
6. Remove the screw from the transport lock, which is only in the plate
carrier compartment (right transport lock in picture above).
7. Slide the transport locks off of the pins and remove them from the
plate carrier.
8. Save the transport locks for further transportation purposes.
STOP
Caution
Save packing materials and transport locks for further transportation
purposes. The infinite
®
200 must be shipped only with the original
packaging and installed transport locks.
